Erisin ES9302A FORD Android Car DVD Player

Audio & Video Appliances
Erisin ES9302A FORD Android Car DVD Player


Offer Type: Sell

Offer Category: Audio & Video Appliances  -  Car DVD

Offer Post Time: 2015-04-23

Serial Code:

Model: ES9302A


Carriage: FOB China

Package: with neutral packing

Minimum Order Quantity: Unknown

Price: 0.00 USD


-Power Supply: DC 12V (allowable range: 10.8-14.5)
-Max Current :10A
-Screen Size:7 inch
-Front Panel Size: 188mm(Top width)*120mm(High)*188mm(Bottom width)
-Package Size: 330mm*260mm*170mm
-Gross Weight: 3.5kg
-Net Weight:3.0kg

-Operation System: Google Android 4.4.4
-CPU: Dual-Core ARMv7 1608MHz
-ROM: 0.98GB
-RAM : 1GB
-Internal SD Card : 5.6GB
-External SD Card:Support TF Card up to 32GB

-Touch Screen:Yes
-Resolution: 1024*600
-Capacitive or Resistance Screen: Capacitive
-Built-in Clock and Calendar: Yes, show real time and can use network-provided time
-DIY main menu Display: Yes, You can drag Search Music/Radio/BT Stereo ,Search bar Bookmarks or App-Icon to main menu
-Change App-Icon Position: Yes
-Display Weather Forecast: Yes

-Connector :On the Back
-WiFi:WiFi Modem included, support 802.11b/g/n
-3G :3G Modem not included, 3G Universal Drive
Support extral USB Dongle:WCDMA,EVDO,TD-SCDMA"

-Explorer :Opera, UCWeb, SkyFile,Dolphin and more Exploer for your selection
-Online Entertainment: Online vedio, TV, movie,music, radio, video chat
-Online Navigation:Online Google Maps Navigating
-Omline Game: Yes, online play or you can download it from google play store
-Online Communication: keep connected through WeChat, Twitter, Facebook, Gtalk, Gmail...
-Read and edit Office Software: Yes, support Word, Excel, Powerpoint, PDF, TXT


-Format:MP3.WMA.MP2.OGG.AAC.M4A.MA4.FLAC.APE.3GP.WAV etc. Could play via song list
-Record :Format: MP3.WMA
-Other : LRC synchronized display; ID3 search; Search by files;Album picture; User-defined audio effect
-Audio IC :Top Global Cirrus IC, independent audio decoding
-SNR : Noise rations: >=90dB


-Format :Support AVI(H.264.DIVX.DIVX.XVID). rm.rmvb. -MKV(H.264.DIVX.DIVX.XVID).WMV.MOV.MP4(.H.264.MPEG.DIVX.XVID).DAT(VCD format).VOB(DVD format).PMP.MPEG..MPG.. FLV(H.263.H.264).ASF .TS. TP.3GP.MPG ect, >=30 formats, playing internet video directly(while downloading)
-Play: Up to1920X1080 pixels. 30Mb. Fluent play without light spot
-Video output :HDMI 720P to1080P. full HD output and common video output(AV)


-Operation System:Android 4.4.4
-Support Maps: IGO, SYGIC maps for Android 4.4.4
-Free 8GB TF Card included: Yes
-Voice Guidance:Yes
-Support 2D/3D Map Views:Yes
-Dual Zone:Yes, navigating while music playing
-Online-Navi:Yes, support google maps online navigating

-Decode IC:8202VGQ
-Compatible Format :MP4, AVI, DIVX, DVD, VCD, MP3, CD, WMA, JPEG
-OSD/Audio/Subtitle Language: English/Italian/French/Spanish/Portuguese/German/Russian...
-Auto-Save Function : Yes, expediently watch all kinds of disc continuously


-Hands Free: Yes
-A2DP (Bluetooth Stereo Music):Yes, can play stereo music through Bluetooth
-Bluetooth Music control :Yes, play/pause/previous/next
-Support PB-Download :Yes, can download phonebook from mobile to this unit
-Support PB-Search: Yes, can use the first letter to search Contact Member in PB-Listings
-Calling Records : Dialed Call, Received Call, Missed Call
-Setup :Auto answer, auto connect, Device name
-Built-in microphone :Yes, on the front panel
-External microphone jack: Yes, on the back


-AM Frequency Range:522-1620KHz
-AM Increment: 9KHz(EU)/10KHz(US)
-FM Tuning Range: 87.5-108MHz
-FM Increment :0.05MHz(EU)/0.1MHz(US)
-FM Area: Europe/USA1/USA2/Japan/Russia
-Preset Stations:30 (FM 3*6, AM 2*6)


-Position: On the Back, USB or 3G Modem Port optional
-Play MP5 Videos: Yes, can play RMVB videos up to 1080P
-Touch music title to play directly:Yes


-Position :On the front panel, Media or GPS Card Slot optional
-Capacity: 32GB micro SD/TF Card
-Play MP5 Videos: Yes, can play RMVB videos up to 1080P
-Touch music title to play directly:Yes

-Built-in Car Recorder :Yes, just connect a USB Camera to use this function
-Support HD CCD Camera:Yes
-Play recorded video directly:Yes
-Show Recorded Video list:Yes, show the time longitude, latitude and speed
-Storing Position: GPS Card

-Built-in TV Tuner: No
-External Port for TV Box: Yes, Support Analog TV/DVB-T/ATSC/ISDB Box
-Power supply to TV Box directly :Yes, you can connect our TV Box to achieve this function
-Touch Control the TV Box on unit : Yes, you can connect our TV Box to achieve this function


-Textbook :Could change font. Font color. Backgroud color.bookmark. Reading E-book while listening music
-Photo Viewer :"Support JPS.BMP.PNG.GIF etc.. format play by revolve powerpoint Support 4096*4096 pixels"
-Wallpapers :8 live wallpapers, 21 wallpapers, support DIY wallpaper from Gallery Pictures
-APK Installer : Support Andorid Package installer
-Support Torque Pro(OBD2&Car): Yes, you can connect a ELM327 Bluetooth OBD2 Scanner Tool to use this function
-Support Mirror Link function: Yes, AirPin(PRO) for iphone and Easy-Connect for Android phone
-Music/Radio Player on main menu :Yes, display a real player on main menu, can be controlled
-Built-in Operation Guide: Yes


-WiFi/GPS/Steering Wheel Control:Yes
-Languages&Input : 60 Languages and Choose Input Method
-Storage/Security/Backup&Reset :Yes
-Add Account/Accessibility: Yes
-Date&Time: Setting Date&Time by yourself or choose GPS automatic update time
-Driving safety/Screenhot setting:Yes
-Display: Brightness/Wallpaper/Wireless display
-Sound :Key Tone & Volume
-Amplifier :PoP/Jazz/Class/Flat/Rock/Voice/Custom
-Apps :Running Apps display/force stop/uninstall
-Factory Settings : Code 126, choose Radio Band and 85 Open-Unit-Logos
-About Device :Display Parameter Info.

-AUX Video In:One
-Rear-view Camera Video In: One
-External Microphone input : One
-AUX Audio In : R/L
-DTV Box Input : One
-Car DVR Input :One
-Radio Antenna Input: One
-GPS Antenna Input : One


-Video Out: Two
-Audio Out : FR/FL/RR/RL
-Surround Stereo Output: 4 x 50w
-Subwoofer Out : One


-FORD Canbus Decoder Box: One
-Power Cable with special Connector: One
-USB OTG Cable : One
-RCA Cable : One
-GPS Antenal Cable : One
-8G Micro SD Card :One
